SBD plummer block housings
One-piece SBD plummer block housings are able to accommodate heavy loads not only acting towards the support surface, but also in other directions. They can be used for
· spherical roller bearings in the 230, 231, 222, 232 series as well as
· CARB bearings in the C 30, C 31, C 22 and C 32 series.
The housings are designed for bearing arrangement types
· bearing on adapter sleeve and smooth shafts with 90 to 400 mm diameter
· bearing on adapter sleeve on stepped shafts with cylindrical seats with 90 to 400 mm diameter and
· bearing on stepped shafts and cylindrical seats with 100 to 420 mm diameter.
Seals
· Labyrinth seals
Lubrication
· Grease lubrication
Materials
· Cast steel
· Grey cast iron
· Spheroidal graphite cast iron
For more information see SKF catalogue "Bearing housings".
Brand SKF FAG NSK KFL
60 SBDD 2213 22213 EK H 313 PSBD 60 95 50 65 45 58 135 165
80 SBDD 2218 22218 EK H 318 PSBD 80 110 60 70 51 55 185 220
90 SBDD 2220 22220 EK H 320 PSBD 90 110 70 85 63 56 195 230
100 SBDD 3122 23122 CCK/W33 H 3122 PSBD 100 150 81 102 83 80 215 270
SBDD 2222 22222 EK H 322 PSBD 100 120 78 90 68 64 215 260
SBDD 3222 23222 CCK/W33 H 2322 PSBD 100 130 91 103 76 90 230 285
